ESL (Electronic Shelf Label)


Empowering Retail DX: Overview & Core Benefits of Smart ESL System

From local groceries to regional electronics chains, we're helping store operators build smarter, low-CAPEX and low-OPEX retail spaces.

If you're exploring Electronic Shelf Labels (ESL), the biggest hidden drawback with conventional systems is often the heavy cloud bandwidth fees and massive server setup costs. At VConn, we took a fundamentally different approach.

Instead of pushing heavy, bandwidth-clogging Image-Based files to every single shelf, we engineered a proprietary Text-Based Transmission Engine.

By transmitting raw text data instead of heavy images, VConn delivers:

[5 Key Benefits of ESL Systems]

  • Seamless POS Integration: Fully synchronizes with your existing POS/ERP systems in real-time via simple APIs, ensuring 100% price accuracy from checkout to the shelf.

  • Up to 90% Lower Cloud Server Costs: Reduces server processing load, bypassing expensive high-end server setups and slashing monthly cloud OPEX.

  • 30% Improved 10-Year Battery Lifespan: Ultra-light text processing maximizes battery efficiency, virtually eliminating ongoing hardware maintenance.

  • 4x Faster Update Speed: Fast, stable connectivity (<1,000 tags per minute) powered by our patented 6-antenna AP design.

  • Rich In-Store Visuals: High-contrast 4-color displays (emulating up to 14 colors) and 4,096-color LED indicators for dynamic promotional cues.

  • Store Operation Freedom: Completely eliminates manual paper tag updates, allowing associates to focus on high-value customer service and inventory tasks.

9666d52c-907a-4f7a-97db-4d54627700a1 (1)_edited.jpg

DP0150A

High-Precision 296×144 Ultra-Low Power E-Paper Display

Features a 154 DPI dot matrix screen for clear text and barcode visibility. Offers BWRY 4-color display and specialized freezer BW options for diverse store environments.MV

W460, MVW490, MVW550, MVW650

  • Dimension [WLH]: 69.4 * 35.3.8 * 11.7

  • Effective display [mm]: 48.6 * 23.65

  • DPI [Pixel]: 154dpi

  • Resolution [Pixel]: 296 * 144

  • Screen: Dot matrix E-paper

  • Screen Color: Black/White/Red/Yellow(BWRY)/ White(Black/White,BW) for freezer

  • Working Temperature: 0~40°C (* DP0266F -25~0°C )

  • Battery: 2x620mAh

  • Battery life: 10 years [2 updates per day]

  • LED Multi-colored LED [Full color]

  • Protocol: 2.4GHz proprietary protocol

  • Accessories: Slide / Rail / Stand / Clip

DP0213A

10-Year Battery Life Powered by Dual-Cell Architecture

MVW460, MVW490, MVW550, MVW650

Equipped with a 2×620mAh battery setup, ensuring up to 10 years of reliable operation based on 2 daily updates. Maximizes battery lifespan to significantly cut down maintenance costs.

  • Dimension [WLH]: 69.4 * 35.3.8 * 11.7

  • Effective display [mm]: 48.6 * 23.65

  • DPI [Pixel]: 154dpi

  • Resolution [Pixel]: 296 * 144

  • Screen: Dot matrix E-paper

  • Screen Color: Black/White/Red/Yellow(BWRY)/ White(Black/White,BW) for freezer

  • Working Temperature: 0~40°C (* DP0266F -25~0°C )

  • Battery: 2x620mAh

  • Battery life: 10 years [2 updates per day]

  • LED Multi-colored LED [Full color]

  • Protocol: 2.4GHz proprietary protocol

  • Accessories: Slide / Rail / Stand / Clip


DP0266A/F

2.4GHz Proprietary Protocol & Multi-Colored LED

Leverages a dedicated 2.4GHz wireless protocol for fast and stable data updates. Integrated full-color LED delivers instant visual alerts for status updates and promotions.

MVW460, MVW490, MVW550, MVW650

  • Dimension [WLH]: 82.0* 41.7 * 11.7

  • Effective display [mm]: 60.1* 30.7

  • DPI [Pixel]: 152dpi

  • Resolution [Pixel]: 360 * 184

  • Screen: Dot matrix E-paper

  • Screen Color: Black/White/Red/Yellow(BWRY)/ White(Black/White,BW) for freezer

  • Working Temperature: 0~40°C (* DP0266F -25~0°C )

  • Battery: 2x620mAh

  • Battery life: 10 years [2 updates per day]

  • LED Multi-colored LED [Full color]

  • Protocol: 2.4GHz proprietary protocol

  • Accessories: Slide / Rail / Stand / Clip

DP0266W

Wide Operating Temperature Down to -25°C

MVW460, MVW490, MVW550, MVW650

Operates seamlessly across standard retail temperatures (0~40°C) and freezer environments (-25~0°C). Delivers reliable display performance in demanding cold-chain applications.

  • Dimension [WLH]: 82.0* 41.7 * 11.7

  • Effective display [mm]: 60.1* 30.7

  • DPI [Pixel]: 152dpi

  • Resolution [Pixel]: 360 * 184

  • Screen: Dot matrix E-paper

  • Screen Color: Black/White/Red/Yellow(BWRY)/ White(Black/White,BW) for freezer

  • Working Temperature: 0~40°C (* DP0266F -25~0°C )

  • Battery: 2x620mAh

  • Battery life: 10 years [2 updates per day]

  • LED Multi-colored LED [Full color]

  • Protocol: 2.4GHz proprietary protocol

  • Accessories: Slide / Rail / Stand / Clip

Gemini_Generated_Image_dvk27pdvk27pdvk2 (1)_edited.jpg

DP0420A/W

Versatile Mounting Accessories

MVW460, MVW490, MVW550, MVW650

Supports a full range of mounting options including Slide, Rail, Stand, and Clip. Enables effortless installation across various store shelf fixtures.

  • Dimension [WLH]: A/ 92.8* 91.8.7 * 12.6, W/ 97.8*91.8*6.9

  • Effective display [mm]: 84.8* 63.6

  • DPI [Pixel]: 120dpi

  • Resolution [Pixel]: 400* 300

  • Screen: Dot matrix E-paper

  • Screen Color: Black/White/Red/Yellow(BWRY)

  • Working Temperature: 0~40°C (* DP0266F -25~0°C )

  • Battery: 1200mAh

  • Battery life: 10 years [2 updates per day]

  • LED Multi-colored LED [Full color]

  • Protocol: 2.4GHz proprietary protocol

  • Accessories: Slide / Rail / Stand / Clip

Screenshot 2026-07-21 at 11.28.26 AM.png

DP0750A

High-Resolution 880×528 Wide E-Paper Screen

MVW460, MVW490, MVW550, MVW650

Delivers an expansive 163.2×97.92mm viewing area with 137 DPI pixel density for clear typography. Optimized for displaying detailed product specifications, QR codes, and rich BWRY promotional graphics.

  • Dimension [WLH]: 178.4*125.6*10.9

  • Effective display [mm]: 163.2*97.92

  • DPI [Pixel]: 137dpi

  • Resolution [Pixel]: 880* 528

  • Screen: Dot matrix E-paper

  • Screen Color: Black/White/Red/Yellow(BWRY)

  • Working Temperature: 0~40°C (* DP0266F -25~0°C )

  • Battery: 1600mAh

  • Battery life: 10 years [2 updates per day]

  • LED Multi-colored LED [Full color]

  • Protocol: 2.4GHz proprietary protocol

  • Accessories: Slide / Rail / Stand / Clip

DP160A

Resilient Thermal Performance Across Retail Environments

MVW460, MVW490, MVW550, MVW650

Operates reliably within a standard 0~40°C range, with optional support for cold-storage facilities down to -25°C. Ensures crisp screen contrast and stable data rendering in both room-temperature and chilled setups.

  • Dimension [WLH]: 263.6*102.7*13.1

  • Effective display [mm]: 244.5*163.0

  • DPI [Pixel]: 99dpi

  • Resolution [Pixel]: 960* 640

  • Screen: Dot matrix E-paper

  • Screen Color: Black/White/Red/Yellow(BWRY)

  • Working Temperature: 0~40°C (* DP0266F -25~0°C )

  • Battery: 1600mAh

  • Battery life: 10 years [2 updates per day]

  • LED Multi-colored LED [Full color]

  • Protocol: 2.4GHz proprietary protocol

  • Accessories: Slide / Rail / Stand / Clip

esl
unnamed (1).jpg

2024 3.5billion USD YoY 40% increase in market size ( expansion in retail stores + phase in in other countries)

2024 Sales: Vusion>Hanshow> Solum, Vusionis a leading company with vertical integration of ESL products + components (PANEL/GLASS)

02

unnamed (6).jpg

ESL Market size is about 52B$. USA(18.8B$) Japan(5B$) Germany(3.7B$)

Out of the top 250 world retail firms, US, Japan, Germany, UK, and France possess 153, which converts to 61% of the market share

Most countries outside Western Europe have an adoption rate of 2-4%

01

unnamed (2).jpg

Offline Labor savings -Focus on core tasks like checkout, Sales improvement -High interest & low activity and, High interest in utilizing digital technology
